Single mast aerial work vehicle (aluminum column)
Lifting hydraulic equipmentAerial worker lift seriesSingle mast seriesOrigin:Mainland
Product introduction
Lifting hydraulic equipment
Aerial Worker Lift Series
Single mast series
Origin: Mainland
Product Specifications
| Type | GTWY6-1006 | GTWY8-1008 | GTWY10-1010 | |
|---|---|---|---|---|
| Platform maximum height m | 6 | 8 | 10 | |
| Maximum working height m | 7.7 | 9.7 | 11.7 | |
| Rated load kg | 160 | 136 | 120 | |
| number of people allowed | 1 | 1 | 1 | |
| Platform size mm | 630*650 | 630*650 | 630*650 | |
| Maximum support size mm | 2060*1900 | 2300*2180 | 2400*2280 | |
| Supply voltage V | AC220 or DC12 | |||
| Input power kw | AC: 0.75, DC: 0.70 | |||
| Dimensions in transport state mm | 1290*880*1740 | 1290*880*2080 | 1390*880*2160 | |
| Self-weight (reference) kg | 390 | 420 | 480 | |
Features
- Reasonably compact design
- Ergonomic control panel
- M-GP device ensures equipment stability
- Hydraulic lines are equipped with explosion-proof valves
- Emergency lowering device for accidental loss of power
- Platform and ground dual operation control
- High strength polyurethane core wheel
- Forklift holes for forklift handling
